Technical parameters |
|---|
| Length of the working table |
600 mm |
| Width of the working table |
300 mm |
| Maximum table load (evenly distributed) |
350 kg |
| Power of the spindle drive |
5.5 kW |
| Number of CNC controlled axles |
3 pcs |
| Number of synchronous axles |
2.5 pcs |
| Minimum rotary speed of the vertical spindle |
40 1/min |
| Maximum rotary speed of the vertical spindle |
4000 1/min |
| Minimum distance of the spindle from the table |
20 mm |
| Maximum distance of the spindle from the table |
400 mm |
| Throat depth (distance of the spindle axis from the frame) |
200 mm |
| Travel length of the quill |
120 mm |
| Travel length X-axis (mechanical feed) |
400 mm |
| Travel length Y-axis (mechanical feed) |
375 mm |
| Travel length Z-axis (mechanical feed) |
250 mm |
| Maximum feed rate in X-axis |
3000 mm/s |
| Maximum feed rate in Y-axis |
3000 mm/s |
| Maximum feed rate in Z-axis |
3000 mm/s |
| Total power demand |
9.5 kW |
| Machine height |
1800 mm |
| Machine length |
1600 mm |
| Machine width |
1600 mm |
| Machine weight |
1450 t |
