CNC Vertical Machining Center OKK PCV-55

Category CNC Milling Machines and Machining Centers OKK ›
Manufacturer OKK ›

ARCHIVED AD
CNC Vertical Machining Center OKK PCV-55 was manufactured by the machine manufacturer OKK. Machine OKK PCV-55 was built in 1998 year.

General data

Location United States
region Wisconsin
Year of manufacture 1998
Warranty Without warranty

Technical parameters

Length of the working table 1219.2 mm
Width of the working table 558.8 mm
Power of the spindle drive 18.7 kW
Number of tools in the magazine 20 pcs
Maximum rotary speed of the vertical spindle 13000 1/min
Travel length X-axis (mechanical feed) 1016 mm
Travel length Y-axis (mechanical feed) 558.8 mm
Travel length Z-axis (mechanical feed) 533.4 mm
Machine height 3048 mm
Machine length 3175 mm
Machine width 2692.4 mm
Machine weight 8.6 t

Equipment

OKK NEOMATIC CONTROL
