Technical parameters |
|---|
| Length of the working table |
1300 mm |
| Width of the working table |
400 mm |
| Power of the spindle drive |
7.4 kW |
| Minimum rotary speed of the vertical spindle |
25 1/min |
| Maximum rotary speed of the vertical spindle |
1200 1/min |
| Maximum distance of the spindle from the table |
540 mm |
| Travel length of the quill |
80 mm |
| Travel length X-axis (mechanical feed) |
1000 mm |
| Travel length Y-axis (mechanical feed) |
340 mm |
| Travel length Z-axis (mechanical feed) |
450 mm |
| Maximum feed rate in X-axis |
33.3 mm/s |
| Maximum feed rate in Y-axis |
33.3 mm/s |
| Maximum feed rate in Z-axis |
13.3 mm/s |
| Total power demand |
10 kW |
| Machine height |
1900 mm |
| Machine length |
3000 mm |
| Machine width |
2400 mm |
| Machine weight |
3.1 t |
